Khoom Taw Qhia
1.Qhov kev pab cuam lub neej ntawm lub sab sauv vuam caj npab yog tsis tsawg tshaj li 3 xyoos; lub qaum vuam log ( beryllium cobalt tooj liab alloy) ￠ 116mm Kev pab lub neej 5 lab cov kaus poom; qis vuam log (beryllium cobalt tooj liab alloy) ￠ 90mm, kev pab lub neej 1.5 lab cov kaus poom; lap pas nrig (hauv qhov ncauj DC53 Khoom) Kev pab lub neej 500 Kaum txhiab
2.Lub laub claw yog tsav los ntawm servo lub cev muaj zog txav mus rau ntawm txoj kab qhia kev tsheb ciav hlau. Lub linear qhia rail yog tsim los ntawm Taiwan Hiwin. Thaum hloov qhov ntev ntawm cov khoom, koj tsuas yog yuav tsum teeb tsa cov khoom sib txuas ntev ntawm lub vijtsam kov, thiab servo lub cev muaj zog yuav khiav raws li qhov xav tau.
3. Txhawm rau tiv thaiv qhov deformation ntawm tooj liab hlau los ntawm kev cuam tshuam cov vuam ntawm lub thoob tom ntej, lub thib ob shaping thiab flattening log nrog lub zog synchronous nrog cov tooj liab hlau ceev yuav tsum tau ntsia nruab nrab ntawm lub siab thiab qis vuam log.
4.Lub vuam lub log sab sauv, qis vuam log thiab vuam transformer yog txias ntawm nws tus kheej los xyuas kom meej lub vuam stability ntawm lub vuam tshuab.
Cov khoom siv technical parameters
1.Workpiece khoom: SPCC, SPCD, hlau substrate
2.Workpiece thickness: 0 4-0.8mm
3.Product welding txoj kab uas hla: Ф320-Ф500 mm
4.Product length: 400mm-1500mm
5.Vuam ceev: 6-15m/min; Kev ua haujlwm zoo: Ntau dua lossis sib npaug li 6 daim / min
6.Barrel sib tshooj dav yuav tsum tau:2.5~3 mm, tooj liab txoj kab uas hla:2 mm
7.Vuam transformer muaj peev xwm: 80KVA
▲ Txhawm rau pab kuv muab cov lus pom zoo rau koj rau cov tshuab kom raug, thov qhia kuv cov ntsiab lus hauv qab no:
A: Kev kos duab / Qhov loj ntawm lub rhaub dej kub sab nrauv koj xav tsim khoom
B: Lub peev xwm ua haujlwm / hnub yog dab tsi?
